Machines made for your production needs.
We specialise in the manufacturing of diamond tool production machines including both arrayed and non-arrayed Cold Press Machines (Multi-station Rotary Disc or Single-mold Line Production). We can also custom-made machines to suit your production needs. Please get in touch to know more.
Features of All Our Arrayed and Non-Arrayed Machines
Crafted to boost production efficiency, minimise material waste, and support both large-scale and small-batch manufacturing.
Capable of producing segments with a base layer for laser welding.
Ensures consistent height of the laser welding base layer across segment, regardless of segment curvature.
Arrayed Diamond Cold Press Machine
Multi-station Rotary Disc Machine (Arrayed) (3DA-5L)
Description
This machine using diamond array cold press method is an all-in-one solution for efficient segment production.
Productivity
320 5-layer segments per hour
Features
Precise control of working powder and diamond powder.
The diamond suction rate is over 98%.
Digital imaging and automatic weighing & sorting systems ensure the density of segments after sintering.
Production with diamond size ranges from 20/25 to 50/60.
Components can be changed easily producing a wide product range.
Technical Details
Power Supply: AC380V
Power Kw: 13 KW
Main machine pressure: 20T
Pre-pressing pressure: 1T
Max. component size: 8cm square
Air consumption: 0.5-0.8MPA, 0.1m3/min
Vacuum: -0.06-0.08MPa, 0.5m3/ min
Dimension(mm) :Ø2050x 2210H
Single-mold Line Production Machine (Arrayed) (3DA-3-5SL)
Description
The line production machine is perfect for small-scale production and prototyping.
Productivity
50 seconds to produce a 5-layer segment
Features
Precise control of working powder and diamond powder.
The diamond suction rate is over 98%.
Digital imaging and automatic weighing & sorting systems ensure the density of segments after sintering.
Production with diamond size ranges from 20/25 to 50/60.
Components can be changed easily producing a wide product range.
Technical Details
Power supply: AC380V
Power: 12Kw
Maximum Pressure: 15T
Maximum component size: 9cm square
Air Consumption: 0.5-0.8MPa, 0.06m3/min
Vacuum: -0.06-0.08MPa, 0.2m3/ min
Dimension (mm): 2423Lx1000Wx 2060H
Non-Arrayed Diamond Cold Press Machine
Multi-station Rotary Disc Cold Press Machine (Non-arrayed) (NA-7L)
Description
Only launched this year, our Multi-station Non-arrayed Machine is ideal for producing ultra-thin segments, thickness as low as 1.2mm after sintering. These segments come with a base layer for laser welding. Perfect for cutting jades, semi-conductor materials, porcelain slabs, etc. This Multi-station model produces 600 7-layer segments in an hour.
Productivity
600 7-layer segments per hour
Features
Each layer are ultra-thin and all powders evenly distributed.
For 7-layer segments, diamonds are typically embedded in the 1st, 3rd, 5th, and 7th layers.
Technical Details
Machine Dimensions: L2000 × W1813 × H2278 (mm)
Machine Weight: 2300 kg
Machine Power: 11 kW
Hydraulic Pump Power: 9 kW
Maximum Hydraulic Pressure: 16 MPa
Power Supply Voltage: AC 380V
Air Pressure: 0.5 – 0.6 MPa
Air Flow Rate: 0.95 m³/min
Single-mold Line Production Cold Press Machine (Non-arrayed) (NA-SL)
Description
A streamlined version of our Multi-station Non-arrayed Machine. It produces ultra-thin segments with a base layer for laser welding. Segment thickness can be as low as 1.2mm. Engineered for flexibility and efficiency, this line model meets your production demands with speed and precision.
Productivity
Only 5 seconds to produce one layer
Features
Each layer are ultra-thin and all powders evenly distributed.
Technical Details
Machine Dimensions: L1675 × W1150 × H2030 (mm)
Machine Weight: 850 kg
Machine Power: 11 kW
Hydraulic Pump Power: 9 kW
Maximum Hydraulic Pressure: 16 MPa
Power Supply Voltage: AC 380V
Air Pressure: 0.5 – 0.6 MPa
Air Flow Rate: 0.7 m³/min
**Yuexi Auto Machinery Co., Ltd. reserves the right to modify technical specifications. Final technical details shall be agreed with the customer.
